RIGOL MSO5354數字示波器顯波器
RIGOL 普源 MSO5354數字示波器顯波器
Rigol MSO5354 Digital OscilloscopeThe MSO5354 is a 350MHz, 4CH high-performance Digital Oscilloscope model design based on RIGOL UltraVision II technology. The MSO5000 series integrates 7 independent instruments into one. The MSO5000 series offers a high sample rate / bandwidth ratio, high memory depth, clear 9 inch touch-screen display, excellent waveform capture rate and powerful data analysis functions. Many of its specifications are industry leading. These instruments are expected to be popular for R&D, universities, production , quality control, communications engineering, automotive engineering, aerospace engineering, industrial and power markets.
Features: Analogue bandwidth: 350 MHz; bandwidth upgrade option supported 2 or 4 analogue channels (upgradeable), standard 16 digital channels(LA probe required) Up to 8 GSa/s real-time sample rate Up to 200 Mpts memory depth (option) High waveform capture rate (over 500,000 wfms/s) Auto measurement of 41 waveform parameters; full-memory hardware measurement function A variety of serial protocol triggers and decodes NEW Bode Plot Analysis – Automate advanced device characterisation with new phase and gain analysis capabilities Up to 450,000 frames of hardware real-time and ceaseless waveforms recording and playback functions Independent search, navigation keys, and event table Built-in advanced power analysis software (option) Integrates 7 independent instruments into 1, including a digital oscilloscope, a logic analyser, a spectrum analyser, an arbitrary waveform generator, a digital voltmeter, a frequency counter and totaliser, and a protocol analyser 9-inch capacitive multi-touch screen, 256-level intensity grading display, with colour persistence Multiple interfaces available: USB HOST&DEVICE, LAN(LXI), HDMI, TRIG OUT, and USB-GPIB Web Control remote command Unique online version upgrade Novel and delicate industrial design, easy to operate Supplied with… 4-off passive probes (500MHz), USB cable, UK & European mains leads, quick guide
Rigol MSO5000 Oscilloscope Comparison Table| MODEL | CHANNELS | BANDWIDTH | MAX SAMPLE RATE | MEMORY | SIGNAL GENERATOR | WAVEFORM REFRESH RATE |
|---|
| MSO5072 | 2 Analogue, 16 Digital (Opt) | 70MHz | 8GSa/s | 100Mpts – Standard
200Mpts – Optional | X2 (Opt) | 500,000 wfm/s | | MSO5074 | 4 Analogue, 16 Digital (Opt) | 70MHz | 8GSa/s | 100Mpts – Standard
200Mpts – Optional | X2 (Opt) | 500,000 wfm/s | | MSO5102 | 2 Analogue, 16 Digital (Opt) | 100MHz | 8GSa/s | 100Mpts – Standard
200Mpts – Optional | X2 (Opt) | 500,000 wfm/s | | MSO5104 | 4 Analogue, 16 Digital (Opt) | 100MHz | 8GSa/s | 100Mpts – Standard
200Mpts – Optional | X2 (Opt) | 500,000 wfm/s | | MSO5204 | 4 Analogue, 16 Digital (Opt) | 200MHz | 8GSa/s | 100Mpts – Standard
200Mpts – Optional | X2 (Opt) | 500,000 wfm/s | | MSO5354 | 4 Analogue, 16 Digital (Opt) | 350MHz | 8GSa/s | 100Mpts – Standard
200Mpts – Optional | X2 (Opt) | 500,000 wfm/s |
|
