Introduction

    SV604 full stroke valve, flange connection , suitable for steam , can not afford chemical applications of industrial gases and water systems.Application    SV604 safety valve for steam boilers , pipes , compressors and cylinders and other protection application process has been most protective equipment    SV604 is PN40/AN300, can raise the standard DIN flanges and ANSI standard flanges . Sealing performance meets API527 standards. According to customer requirements to provide a soft seal spool .    Spirax Sarco SV604 safety valve is widely used in food, beverage , petrochemical , steel, metallurgy , power plants and other fields, is the best choice for pressure vessels and piping equipment overpressure protection .    Spirax Sarco advanced valve design , full range , the material widely ( bronze, ductile iron , carbon steel, alloy steel, stainless steel and other materials ) , widely used in the temperature range , all products are certified authority . To provide a safety valve meets the requirements of the different standards .In the vacuum station system, in order to prevent the rated pressure relief valve downstream pressure is higher than the equipment operation , valves must be installed downstream of the valve . Pressure relief valve must be set within the maximum allowable operating pressure range of the device between the normal operating pressure and there is enough pressure to prevent the valve sealing surface damage resulting in frequent jump . Relief valve setting must be performed by qualified personnel. When the safety valve selection should guarantee the safety valve set pressure through the valve can flow through the maximum flow .The following parameters:1 , system or equipment must displacement and the proposed number of valves installed .2, the opening pressure ( or set pressure )3 , and the proportion of medium (liquid medium ) or molecular weight and compressibility factor ( for gaseous media )4, the valve inlet medium temperature5 , if there is back pressure , if any, is the number6 , requires valve performance standards ( eg no special specified , specified by the supplier

 SV604全行程安全閥,法蘭連接,適用于蒸汽、不起化學作用的工業氣體和水系統的應用。

應用

    斯派莎克SV604安全閥適用于蒸汽鍋爐、管道、壓縮機和儲氣罐等的保護已經大多數制程設備的保護應用

    SV604為PN40/AN300,可提DIN標準法蘭和ANSI標準法蘭。密封性能符合API527標準。根據客戶要求可提供軟密封閥芯。

    斯派莎克SV604安全閥廣泛地應用于食品、飲料、石油化工、鋼鐵、冶金、電站等領域,是管道壓力容器和設備超壓保護的*選擇。

    斯派莎克安全閥設計先進,品種齊全,材質廣泛(青銅、球鐵、碳鋼、合金鋼、不銹鋼等材質),使用溫度范圍廣泛,所有產品均有權威機構的認證。斯派莎克SV604安全閥,能提供符合不同標準要求的安全閥。

在安全閥選型是,應保證安全閥在設定壓力下能通過減壓閥所能流過的*流量。

SV615安全閥:全行程、全噴嘴安全閥。適用于蒸汽、空氣不起化學作用的工業氣體和非危險液體的應用。

用于蒸汽或熱水鍋爐,發生器、壓力容器、儲氣罐和空氣壓縮機,高壓釜減壓閥的下游保護等。

口徑DN15-200,壓力PN25,螺紋BSP或NPT連接或法蘭連接,

對于DN15-25可提供衛生級卡箍連接。

密封性能符合API527標準。可提供軟密封閥芯。

SV607/SV604安全閥:全行程法蘭連接安全閥。主要應用于蒸汽鍋爐管道。壓力容器、壓縮機和儲氣罐等的防護及大多數設備的防護。

SV73鑄鐵系列安全閥SV74鑄鋼系列安全閥符合ASME Ⅰ和ASME Ⅷ制造標準。

斯派莎克SV60安全閥主要用于需要ASME Ⅰ和ASME Ⅷ鋼印的動力鍋爐和不用火加熱的壓力容器上。如安裝于空氣盤管、換熱器或過程容器等的進口前,保護減壓閥下游的蒸汽系統。

也可用于冷凝水回收系統的閃蒸罐上,保護閃蒸罐,保護壓縮空氣系統的壓縮機或儲氣罐不超壓。保護蒸汽鍋爐或蒸汽發生器。
